Beschreibung des Produkts

Introduction of HONPINE TDB-170-050-NH-A Direct Drive Torque Motor

The TDB-170-050-NH-A torque motor is a low-speed, high-torque DC motor with precise control. Its key features include the elimination of transmission errors, high rigidity with low vibration, fast response, and low maintenance requirements. It is commonly used in precision automation equipment such as semiconductor wafer processing machines, precision indexing tables, high-accuracy direct-drive turntables, and LCD panel handling systems.

Specification of TDB-170-050-NH-A Direct Drive Torque Motor

Performance	Unit	Performance	Unit
Continuous Torque	6 N ·m	Peak Torque	18 N ·m
Continuing Current	2 Arms	Peak Current	6 Arms
Rated power	220 W	Torque constant	3 N ·m/Arms
Resistance@25℃	6 Ohms L-L	Inductance	7.5 mH
Back-EMF constant@25℃	2.7 Vrms/rad/s	Moment of Inertia	0.0066 Kg ·m^2
Accuracy	±15Arc sec	Repeatability	±2 Arc sec
Max.Axial Load	2000 N	Max.Moment Load	60 N ·m
Axial Runout	5 um	Radial Runout	5 um
Max.Speed	350 rpm	Mass of Motor	3.7 Kg
Pole Number	30	Resolution	23 bit Biss-C
Diameter	170 mm	Height	50 mm

Introduction of HONPINE Direct Drive Torque Motor Factory

HONPINE specializes in the R&D and manufacturing of direct drive torque motors, having established a 5,000-square-meter facility dedicated to the development, production, and administration of its direct drive motor product lines. The facility is equipped with a comprehensive array of advanced machinery, including dynamometers, fully automated winding machines, CNC machining centers, laser interferometers, automated potting machines, and salt spray test chambers. Furthermore, the company has established sales and after-sales service centers in Singapore, Suzhou, and Shenzhen. To support the localization of semiconductor equipment manufacturing, the company commissioned a precision assembly cleanroom and an R&D laboratory in 2024. HONPINE has successfully obtained quality certifications such as ISO9001 and CE, and its independently developed products have been awarded dozens of patents for both inventions and utility models.
